Applied Models

Supports creating volumes across different units

23 series:DS1823xs+, DS923+, DS723+
22 series:DS1522+
21 series:DS1821+, DS1621xs+, DS1621+, DVA3221
20 series:DS1520+, DS920+, DS720+
19 series:DS1819+, DS1019+, DVA3219
18 series:DS1618+, DS918+, DS718+, NVR1218
17 series:DS1817+, DS1817, DS1517+, DS1517
16 series:DS916+, DS716+II, DS716+
15 series:DS1815+, DS1515+, DS1515

Supports creating volumes on a single unit only

18 series:DS218+
16 series:DS216+II, DS216+, NVR216
15 series:DS415+

Notes

For more information on the compatibility of each expansion unit, please refer to this article.
Please upgrade to DSM 6.2.1-23824-5 or later version before using it with 15 and 16 series models (excluding DS1515, DS716+, and DS716+II).
To have better performance, we recommend creating storage volumes physically located within the same NAS or Expansion Unit, rather than creating volumes across your NAS and Expansion Unit.

Storage

Drive Bays

5

Drive Type (See all supported drives)

3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD

Hot Swappable Drive*

✓

RAID Management through Synology DSM

✓

Notes

Synology only guarantees full functionality, reliability, and performance for Synology drives listed on the compatibility list. The use of non-validated components may limit certain functionality and result in data loss and system instability.

External Ports

eSATA Port

1

Appearance

Size (Height x Width x Depth)

157 mm x 248 mm x 233 mm

Weight

3.91 kg

Power

Power Recovery

Synchronized with the Synology DiskStation

Power Supply Unit / Adapter

200 W

AC Input Power Voltage

100V to 240V AC

Power Frequency

50/60 Hz, Single Phase

Power Consumption

29.9 W (Access)
2.4 W (HDD Hibernation)

British Thermal Unit

102.02 BTU/hr (Access)
8.19 BTU/hr (HDD Hibernation)

Notes

Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).

Temperature

Operating Temperature

5°C to 40°C (40°F to 104°F)

Storage Temperature

-10°C to 70°C (15°F to 155°F)

Operating Humidity

8% to 80% RH

Storage Humidity

5% to 95% RH

Others

System Fan

80 mm x 80 mm x 2 pcs

Easy Replacement System Fan

✓

Noise Level*

21.5 dB(A)

Notes

Noise Level Testing Environment: Fully loaded with Seagate 1TB ST31000520AS hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%

Certification

Certification

FCC
CE
BSMI
BIS

Warranty

Warranty

3-year hardware warranty

Notes

Availability varies by region. Before purchasing, please visit the official web pages of EW201/202 and Extended Warranty Plus for a list of eligible regions.
The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)

Environment

Environment

RoHS Compliant

Packaging Content

Packaging Content

Main Unit X 1
Accessory Pack X 1
AC Power Cord X 1
Expansion Cable: eSATA X 1
Quick Installation Guide X 1

Optional Accessories

Optional Accessories

Enterprise Series 3.5" SATA HDD: HAT5300 Series
Plus Series 3.5" SATA HDD: HAT3300 Series
Enterprise Series 2.5" SATA SSD: SAT5200 Series
